TAGP4561Z R404a 3 Phase compressor
Product code:
C7074P
Manufacturer code
2846030102
General Information
| Product Group : | Hermetic |
|---|---|
| Cylinder Volume : | 112.5 cm³ |
Additional Info
| Family : | TAGP |
|---|
Capacity
| Capacity at -10°C : | 5.90 kW |
|---|---|
| Capacity at 0°C : | 10.45 kW |
| Capacity at 15°C : | 20.23 kW |
Capacity R404A
| R404A Capacity -5°C : | 9082 W |
|---|
Capacity R448A/449A
| R448A/449A Capacity -5°C : | 8586 W |
|---|---|
| R448A/449A Capacity -10°C : | 7657 W |
| R448A/449A Capacity 0°C : | 12994 W |
| R448A/449A Capacity 5°C : | 16501 W |
Compressor
| Displacement : | 112.5 cc |
|---|
Connections
| Discharge Connection Pipe Size : | 5/8 in |
|---|---|
| Discharge Line Connection : | 5/8 in |
| Suction Connection Pipe Size : | 1 1/8 in |
| Suction Line Connection : | 1/2 in |
Electrical
| Max Current : | 14.0 A |
|---|---|
| Max Power Input : | 5.3 kW |
| Phase : | 3 |
| Power Supply : | 400 V |
| RLA : | 15.3 A |
Material
| Connection Material : | Copper-plated steel |
|---|
Measurements
| Height : | 409 mm |
|---|---|
| Length : | 261 mm |
| Weight : | 46 kg |
| Width : | 224 mm |
Oil
| Oil : | POE 32 |
|---|---|
| Oil Quantity : | 1.96 dm³ |
Performance
| Horsepower : | 5 HP |
|---|
Refrigerant
| GWP : | 1387 |
|---|---|
| Refrigerant : | R448A, R449A |
